Advantages:
1. Advanced lithium iron phosphate technology, top grade battery control system
2. Modular structure which can form varieties of energy levels, small size, convenient to maintain
3. Modular design, fast transportation and installation, easy to use
4. Ten years warranty, one stop service
5. Top level electric and structure design, silence enjoyment
6. Remote control system for APP, visual data
Electrical Characteristics:
|
Model |
RP-WM48200 |
|
Battery Type |
LiFePO4 |
|
Battery Cabinet Configuration |
1 |
| Nominal Voltage | 48V |
|
Nominal Capacity |
200Ah |
|
Nominal Total Energy |
9.6kWh |
|
Electrical Parameters |
|
|
Voltage Range |
40.5~54V |
|
Standard Charging Current |
50A |
|
Max.Charging Current |
100A |
|
Standard Discharge Current |
50A |
|
Max.Discharging Current |
100A |
|
Mechanical Parameters |
|
|
Net Weight |
~92kg |
|
Dimension (W*D*H) |
680*485*226mm |
|
Ingress Protection |
IP65 |
|
Cooling |
Natural Cooling |
|
Operation Condition |
|
|
Environment Temperature |
Charge:0℃~55℃/ Discharge:-20℃~55℃/ Storage:-10℃~30℃ |
|
Operation Humidity |
5~95%,RH |
|
Altitude |
< 2000m |
|
Mounting Type |
Floor-mounted |
|
Design Life |
> 10 years |
Compatible Inverters:
If you need other voltage and capacity battery, please feel free to contact us
\
